This case collar lathe can be defined as a revolution in the field of turning. Its measurement setting system is
completely innovative, it allows you once you have decided the thickness of the
collar you want to make to set it with extreme precision even
before starting. This will allow you to waste very little time
during preparation, no wasted shells and caliber changes
very fast. Made entirely in CNC machining centers with i
best materials was created for those who use the milling machine or drill press for
this processing. It allows to carry out this operation in the way
best and professional. The body with an excursion of +/-3mm allows
turning the lateral adjustment screw to find the desired adjustment
in minutes without moving the cutting edge. On the side opposite the cutting edge
we find the seat for the centesimal comparator that will allow you to
always have the size and oscillation of the turning under control. It comes standard with a 30° cutting edge (the 40° one can be purchased as an accessory) and uses a Sinclair pilot or similar with a diameter
at the base 9.5mm.
(pilot and comparator not included).
completely on CNC machining centers with the best materials, it has the particularity of having the hole for the pilot offset from the centre. This
makes it quirky. This peculiarity means that turning the base after
having loosened the special screw that holds it in position, you can vary the
thickness of the collar of +/-0.2mm compared to the starting size, without
minimally move the cutting edge. The notches present make it much easier
the regolation. On the opposite side to the housing of the cutting edge is present
the seat for assembling the centesimal comparator in mm, which there
will let you know in real time the thickness of the collar and make you
account the degree of accuracy. The cutting edge used is made of metal
hard and has an angle of 30° (the 40° one can be purchased as an accessory). The pilots to be used are those of Sinclair, this one
guarantees maximum freedom of choice on calibers and availability.
(comparator and pilot not included).
